TIBPAL16R8-20MFKB 5962-85155022A TI OT PLD, 15ns, PAL-Type, TTL, LCC20
Tax included.
THIS LISTING IS FOR (1 PC) OF TIBPAL16R8-20MFKB 5962-85155022A BY TI
OT PLD, 15ns, PAL-Type, TTL, CQCC20
Part #: TIBPAL16R8-20MFKB
Part Category: Programmable Logic ICs
Manufacturer: Texas Instruments High-Performance Analog
Description: OT PLD, 15ns, PAL-Type, TTL, CQCC20
Mfr Package Description LCC-20
Status NRFND
Programmable Logic Type OT PLD
Architecture PAL-TYPE
Clock Frequency-Max 41.6 MHz
In-System Programmable NO
JESD-30 Code S-CQCC-N20
JTAG BST NO
Number of Dedicated Inputs 8.0
Number of I/O Lines 0.0
Number of Inputs 8.0
Number of Outputs 8.0
Number of Product Terms 64.0
Number of Terminals 20
Operating Temperature-Min -55.0 Cel
Operating Temperature-Max 125.0 Cel
Organization 8 DEDICATED INPUTS, 0 I/O
Output Function REGISTERED
Package Body Material CERAMIC, METAL-SEALED COFIRED
Package Code QCCN
Package Equivalence Code LCC20,.35SQ
Package Shape SQUARE
Package Style CHIP CARRIER
Packing Method TUBE
Peak Reflow Temperature (Cel) NOT SPECIFIED
Power Supplies 5
Propagation Delay 15.0 ns
Qualification Status Not Qualified
Screening Level MIL-PRF-38535
Seated Height-Max 2.03 mm
Sub Category Programmable Logic Devices
Supply Voltage-Nom 5.0 V
Supply Voltage-Min 4.5 V
Supply Voltage-Max 5.5 V
Surface Mount YES
Technology TTL
Temperature Grade MILITARY
Terminal Form NO LEAD
Terminal Pitch 1.27 mm
Terminal Position QUAD
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Length 8.89 mm
Width 8.89 mm
