SNJ54ABT16240WD Bus Driver, 4-Func, 4-Bit, Inverted Output, BICMOS, CDFP48
Tax included.
This listing is for (1PC) of SNJ54ABT16240WD by Texas Instruments
tatus Discontinued
Logic IC Type BUS DRIVER
Sub Category Bus Driver/Transceivers
Control Type ENABLE LOW
Family ABT
JESD-30 Code R-GDFP-F48
Load Capacitance (CL) 50.0 pF
Max I(ol) 0.048 Amp
Number of Bits 4
Number of Functions 4
Number of Ports 2
Number of Terminals 48
Operating Temperature-Min -55.0 Cel
Operating Temperature-Max 125.0 Cel
Output Characteristics 3-STATE
Output Polarity INVERTED
Package Body Material CERAMIC, GLASS-SEALED
Package Code DFP
Package Equivalence Code FL48,.4,25
Package Shape RECTANGULAR
Package Style FLATPACK
Peak Reflow Temperature (Cel) NOT SPECIFIED
Power Supply Current-Max (ICC) 32.0 mA
Prop. Delay@Nom-Sup 4.9 ns
Propagation Delay (tpd) 4.9 ns
Qualification Status Not Qualified
Screening Level 38535Q/M;38534H;883B
Seated Height-Max 3.05 mm
Supply Voltage-Nom (Vsup) 5
Supply Voltage-Min (Vsup) 4.5 V
Supply Voltage-Max (Vsup) 5.5 V
Surface Mount YES
Technology BICMOS
Terminal Form FLAT
Terminal Pitch 0.635 mm
Terminal Position DUAL
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Length 15.748 mm
Width 9.652 mm
Additional Feature TYP VOLP < 1V @ VCC 5V, TA 25 DEG C
