PE320240WRF-001-HQ Powertip LCD Display 320x240
Tax included.
THIS LISTING IS FOR (1) PE320240WRF-001-HQ BY POWETIP
Display Type 320 * 240 Dots
LCD Type FSTN, Positive, Transflective
Driver Condition LCD Module: 1/240 Duty, 1/15 Bias
Viewing Direction 6 O’clock
Backlight LED B/L
Weight 140g
Interface 4 bits parallel data input
Controller IC Driver IC Sitronix ST8024 , ST8016
Outline Dimension 143.0 (L) * 96.8 (w) * 12.6(H)(Max) mm
Viewing Area 106.0 (L) * 81.0 (w) mm
Active Area 95.985 (L) *71.985 (w) mm
Dot Size 0.285 (L) * 0.285 (w) mm
Dot Pitch 0.30 (L) * 0.30 (w) mm
