M4-64/32-15JC LATTICE EE PLD 15ns 64-Cell CMOS PLCC44
Tax included.
THIS IS FOR (1 PC) OF M4-64/32-15JC BY LATTICE
EE PLD 15ns 64-Cell CMOS PLCC44
Part #: M4-64/32-15JC
Part Category: Programmable Logic ICs
Manufacturer: Lattice Semiconductor Corporation
Description: EE PLD, 15ns, 64-Cell, CMOS, PQCC44
Mfr Package Description PLASTIC, LCC-44
Status Discontinued
Programmable Logic Type EE PLD
Clock Frequency-Max 37.0 MHz
In-System Programmable YES
JESD-30 Code S-PQCC-J44
JESD-609 Code e0
JTAG BST YES
Moisture Sensitivity Level 3
Number of Dedicated Inputs 0.0
Number of I/O Lines 32.0
Number of Macro Cells 64.0
Number of Terminals 44
Operating Temperature-Min 0.0 Cel
Operating Temperature-Max 70.0 Cel
Organization 0 DEDICATED INPUTS, 32 I/O
Output Function MACROCELL
Package Body Material PLASTIC/EPOXY
Package Code QCCJ
Package Equivalence Code LDCC44,.7SQ
Package Shape SQUARE
Package Style CHIP CARRIER
Peak Reflow Temperature (Cel) 225
Power Supplies 5
Propagation Delay 15.0 ns
Qualification Status Not Qualified
Seated Height-Max 4.57 mm
Sub Category Programmable Logic Devices
Supply Voltage-Nom 5.0 V
Supply Voltage-Min 4.75 V
Supply Voltage-Max 5.25 V
Surface Mount YES
Technology CMOS
Temperature Grade COMMERCIAL
Terminal Finish TIN LEAD
Terminal Form J BEND
Terminal Pitch 1.27 mm
Terminal Position QUAD
Time@Peak Reflow Temperature-Max (s) 30
Length 16.5862 mm
Width 16.5862 mm
Additional Feature YES
