CD4023BCN/MM5623BN NSC NAND Gate, 3-Func, 3-Input, CMOS, PDIP14
Tax included.
This listing is for (5pcs) of CD4023BCN/MM5623BN by NSC
Mfr Package Description PLASTIC, DIP-14
REACH Compliant Yes
Status Transferred
Logic IC Type NAND GATE
Sub Category Gates
Family 4000/14000/40000
JESD-30 Code R-PDIP-T14
JESD-609 Code e0
Load Capacitance (CL) 50.0 pF
Number of Functions 3
Number of Inputs 3.0
Number of Terminals 14
Operating Temperature-Min -40.0 Cel
Operating Temperature-Max 85.0 Cel
Package Body Material PLASTIC/EPOXY
Package Code DIP
Package Equivalence Code DIP14,.3
Package Shape RECTANGULAR
Package Style IN-LINE
Prop. Delay@Nom-Sup 250.0 ns
Propagation Delay (tpd) 250.0 ns
Qualification Status Not Qualified
Schmitt Trigger NO
Seated Height-Max 5.08 mm
Supply Voltage-Nom (Vsup) 5
Supply Voltage-Min (Vsup) 3.0 V
Supply Voltage-Max (Vsup) 15.0 V
Surface Mount NO
Technology CMOS
Temperature Grade INDUSTRIAL
Terminal Finish Tin/Lead (Sn/Pb)
Terminal Form THROUGH-HOLE
Terminal Pitch 2.54 mm
Terminal Position DUAL
Length 19.18 mm
Width 7.62 mm
