(8PCS) L6006D8 L6006D8TP Triacs 600V 6A Sensing 10-10-10-20mA
Tax included.
THIS LISTING IS FOR (8PCS) OF L6006D8TP BY LITTELFUSE
anufacturer: Littelfuse
Product Category: Triacs
RoHS: Details
Series: Lxx06xx
On-State RMS Current - It RMS: 6 A
Non Repetitive On-State Current: 50 A, 60 A
Rated Repetitive Off-State Voltage VDRM: 600 V
Off-State Leakage Current @ VDRM IDRM: 20 uA
On-State Voltage: 1.6 V
Holding Current Ih Max: 20 mA
Gate Trigger Voltage - Vgt: 2 V
Gate Trigger Current - Igt: 10 mA, 20 mA
Minimum Operating Temperature: - 40 C
Maximum Operating Temperature: + 110 C
Mounting Style: SMD/SMT
Package / Case: TO-252-3
Packaging: Tube
Brand: Littelfuse
Product Type: Triacs
