(5PCS) UC2525AN Voltage Mode PWM Controller 400mA 16-Pin PDIP
Tax included.
THIS LISTING IS FOR (5PCS) OF UC2525AN BY TEXAS INSTRUMENTS
SPECIFICATIONS
| Mfr Package Description | GREEN, PLASTIC, DIP-16 |
| REACH Compliant | Yes |
| EU RoHS Compliant | Yes |
| China RoHS Compliant | Yes |
| Status | Active |
| Analog IC - Other Type | SWITCHING CONTROLLER |
| Control Mode | VOLTAGE-MODE |
| Control Technique | PULSE WIDTH MODULATION |
| Input Voltage-Nom | 20 V |
| Input Voltage-Min | 8 V |
| Input Voltage-Max | 35 V |
| JESD-30 Code | R-PDIP-T16 |
| JESD-609 Code | e4 |
| Moisture Sensitivity Level | NOT APPLICABLE |
| Number of Functions | 1 |
| Number of Terminals | 16 |
| Operating Temperature-Min | -25 Cel |
| Operating Temperature-Max | 85 Cel |
| Output Current-Max | 0.5000 A |
| Output Voltage-Nom | 5.1 V |
| Package Body Material | PLASTIC/EPOXY |
| Package Code | DIP |
| Package Equivalence Code | DIP16,.3 |
| Package Shape | RECTANGULAR |
| Package Style | IN-LINE |
| Peak Reflow Temperature (Cel) | NOT APPLICABLE |
| Qualification Status | Not Qualified |
| Seated Height-Max | 5.08 mm |
| Sub Category | Switching Regulator or Controllers |
| Surface Mount | NO |
| Switcher Configuration | PUSH-PULL |
| Switching Frequency-Max | 400 kHz |
| Technology | BIPOLAR |
| Temperature Grade | OTHER |
| Terminal Finish | Nickel/Palladium/Gold (Ni/Pd/Au) |
| Terminal Form | THROUGH-HOLE |
| Terminal Pitch | 2.54 mm |
| Terminal Position | DUAL |
| Time@Peak Reflow Temperature-Max (s) | NOT APPLICABLE |
| Length | 19.3 mm |
| Width | 7.62 mm |
