| EU RoHS |
Compliant with Exemption
|
| ECCN (US) |
EAR99 |
| Part Status |
Active |
| Configuration |
Single |
| Direction Type |
Bi-Directional |
| Number of Elements per Chip |
1 |
| Minimum Breakdown Voltage (V) |
44.4 |
| Maximum Clamping Voltage (V) |
64.5 |
| Maximum Reverse Stand-Off Voltage (V) |
40 |
| Peak Forward Surge Current (A) |
600 |
| Maximum Peak Pulse Current (A) |
79.1 |
| Maximum Reverse Leakage Current (uA) |
10 |
| Test Current (mA) |
5 |
| Peak Pulse Power Dissipation (W) |
5000 |
| Minimum Operating Temperature (°C) |
-55 |
| Maximum Operating Temperature (°C) |
175 |
| Operating Junction Temperature (°C) |
-55 to 175 |
| Supplier Temperature Grade |
Automotive |
| Pin Count |
2 |
| Packaging |
Tape and Reel |
| Supplier Package |
Case P-600 |
| Standard Package Name |
Case P-600 |
| Diameter |
9.1(Max) |
| Mounting |
Through Hole |
| Package Length |
9.1(Max) |
| PCB changed |
2 |
| Lead Shape |
Through Hole |
