(5PCS) MTFC8GLVEA-4MIT IC FLASH 64GBIT 153WFBGA
Tax included.
THIS LISITING IS FOR (3PCS) OF MTFC8GLVEA-4MIT BY MICRON
SPECIFICATIONS
| Mfr Package Description | 11.50 X 13 MM, 0.80 MM HEIGHT, ROHS COMPLIANT, WFBGA-153 |
| EU RoHS Compliant | Yes |
| Status | Discontinued |
| Microprocessor/Microcontroller/Peripheral IC Type | MICROPROCESSOR CIRCUIT |
| JESD-30 Code | R-PBGA-B153 |
| JESD-609 Code | e1 |
| Number of Terminals | 153 |
| Operating Temperature-Min | -40.0 Cel |
| Operating Temperature-Max | 85.0 Cel |
| Package Body Material | PLASTIC/EPOXY |
| Package Code | VFBGA |
| Package Shape | RECTANGULAR |
| Package Style | GRID ARRAY, VERY THIN PROFILE, FINE PITCH |
| Peak Reflow Temperature (Cel) | 260 |
| Seated Height-Max | 0.8 mm |
| Supply Voltage-Nom | 1.8 V |
| Supply Voltage-Min | 1.65 V |
| Supply Voltage-Max | 1.95 V |
| Surface Mount | YES |
| Technology | CMOS |
| Temperature Grade | INDUSTRIAL |
| Terminal Finish | TIN SILVER COPPER |
| Terminal Form | BALL |
| Terminal Pitch | 0.5 mm |
| Terminal Position | BOTTOM |
| Time@Peak Reflow Temperature-Max (s) | 30 |
| Length | 13.0 mm |
| Width | 11.5 mm |
| Additional Feature | IT ALSO OPERATES AT 3.3 VOLTS |
