| EU RoHS |
Compliant
|
| ECCN (US) |
EAR99 |
| Type |
Electrolytic |
| Capacitance Value |
100uF |
| Tolerance |
20% |
| Voltage |
35VDC |
| Equivalent Series Resistance Type |
Low |
| Maximum Impedance (Ohm) |
0.117@20°C@100kHz |
| IR (mA) |
555 |
| IL (uA) |
35@2Min |
| Lifetime (h) |
2000 |
| Polarity |
Polar |
| Construction |
Aluminum Cylindrical Can |
| Mounting |
Through Hole |
| Termination Style |
Radial |
| Number of Terminals |
2 |
| Terminal Pitch (mm) |
3.5 |
| Wire Form |
Long Lead |
| Size (mm) |
8 X 11.5 |
| Minimum Operating Temperature (°C) |
-55 |
| Maximum Operating Temperature (°C) |
105 |
| Packaging |
Bulk |
| Product Diameter (mm) |
8 |
| Product Height (mm) |
11.5 |
| Lead Diameter (mm) |
0.6 |
