| EU RoHS |
Compliant
|
| ECCN (US) |
EAR99 |
| Type |
Switching Diode |
| Material |
Si |
| Configuration |
Single |
| Peak Reverse Repetitive Voltage (V) |
600 |
| Maximum Continuous Forward Current (A) |
9.5 |
| Peak Non-Repetitive Surge Current (A) |
225 |
| Peak Forward Voltage (V) |
1.6 |
| Peak Reverse Current (uA) |
100 |
| Peak Reverse Recovery Time (ns) |
4000(Typ) |
| Minimum Operating Temperature (°C) |
-40 |
| Maximum Operating Temperature (°C) |
125 |
| Packaging |
Tube |
| Supplier Package |
TO-220AB |
| Pin Count |
3 |
| Mounting |
Through Hole |
| Package Height |
9.4(Max) |
| Package Length |
10.67(Max) |
| Package Width |
4.78(Max) |
| PCB changed |
3 |
| Tab |
Tab |
