(5PCS) BDW84C Power Bipolar Transistor, 15A, 100V, 1-Element, PNP, TO-204
(5PCS) BDW84C Power Bipolar Transistor, 15A, 100V, 1-Element, PNP, TO-204
(5PCS) BDW84C Power Bipolar Transistor, 15A, 100V, 1-Element, PNP, TO-204

(5PCS) BDW84C Power Bipolar Transistor, 15A, 100V, 1-Element, PNP, TO-204

Tax included.
Only 37 left!
This listing is for (5pcs) of BDW84C by Bourns


Mfr Package Description HERMETIC SEALED, METAL, TO-3, 2 PIN
REACH Compliant Yes
Status Active-Unconfirmed
Case Connection COLLECTOR
Collector Current-Max (IC) 15.0  A
Collector-emitter Voltage-Max 100.0  V
Configuration SINGLE
DC Current Gain-Min (hFE) 750.0
JEDEC-95 Code TO-204AA
JESD-30 Code O-MBFM-P2
Number of Elements 1.0
Number of Terminals 2
Package Body Material METAL
Package Shape ROUND
Package Style FLANGE MOUNT
Peak Reflow Temperature (Cel) NOT SPECIFIED
Polarity/Channel Type PNP
Qualification Status Not Qualified
Surface Mount NO
Terminal Form PIN/PEG
Terminal Position BOTTOM
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Transistor Element Material SILICON
Transition Frequency-Nom (fT) 1.0  MHz
