(5PCS) ADM485AR Single Transmitter/Receiver RS-422/RS-485 8-Pin SOIC
Tax included.
THIS LISTING IS FOR (5PCS) OF ADM485AR BY ANALOG DEVICES
SPECIFICATIONS
Mfr Package Description
MS-012AA, SOIC-8
REACH Compliant
Yes
Status
Active
Interface IC Type
LINE TRANSCEIVER
Differential Output
YES
Driver Number of Bits
1.0
High Level Input Current-Max
1.0E-6 Amp
Input Characteristics
DIFFERENTIAL SCHMITT TRIGGER
Interface Standard
EIA-422; EIA-485
JESD-30 Code
R-PDSO-G8
JESD-609 Code
e0
Moisture Sensitivity Level
1
Number of Functions
1
Number of Terminals
8
Operating Temperature-Min
-40.0 Cel
Operating Temperature-Max
85.0 Cel
Out Swing-Min
1.5 V
Output Characteristics
3-STATE
Output Low Current-Max
0.004 Amp
Output Polarity
COMPLEMENTARY
Package Body Material
PLASTIC/EPOXY
Package Code
SOP
Package Equivalence Code
SOP8,.25
Package Shape
RECTANGULAR
Package Style
SMALL OUTLINE
Peak Reflow Temperature (Cel)
235
Power Supplies (V)
5
Qualification Status
Not Qualified
Receive Delay-Max
40.0 ns
Receiver Number of Bits
1.0
Seated Height-Max
1.75 mm
Sub Category
Line Driver or Receivers
Supply Current-Max
2.2 mA
Supply Voltage-Nom
5.0 V
Supply Voltage-Min
4.75 V
Supply Voltage-Max
5.25 V
Surface Mount
YES
Technology
BICMOS
Temperature Grade
INDUSTRIAL
Terminal Finish
Tin/Lead (Sn85Pb15)
Terminal Form
GULL WING
Terminal Pitch
1.27 mm
Terminal Position
DUAL
Time@Peak Reflow Temperature-Max (s)
20
Transmit Delay-Max
15.0 ns
Length
4.9 mm
Width
3.9 mm
Additional Feature
1 RECEIVER ACTIVE UNDER SHUTDOWN; COMMON I/O; TRISTATABLE RECEIVERS
| Mfr Package Description | MS-012AA, SOIC-8 |
| REACH Compliant | Yes |
| Status | Active |
| Interface IC Type | LINE TRANSCEIVER |
| Differential Output | YES |
| Driver Number of Bits | 1.0 |
| High Level Input Current-Max | 1.0E-6 Amp |
| Input Characteristics | DIFFERENTIAL SCHMITT TRIGGER |
| Interface Standard | EIA-422; EIA-485 |
| JESD-30 Code | R-PDSO-G8 |
| JESD-609 Code | e0 |
| Moisture Sensitivity Level | 1 |
| Number of Functions | 1 |
| Number of Terminals | 8 |
| Operating Temperature-Min | -40.0 Cel |
| Operating Temperature-Max | 85.0 Cel |
| Out Swing-Min | 1.5 V |
| Output Characteristics | 3-STATE |
| Output Low Current-Max | 0.004 Amp |
| Output Polarity | COMPLEMENTARY |
| Package Body Material | PLASTIC/EPOXY |
| Package Code | SOP |
| Package Equivalence Code | SOP8,.25 |
| Package Shape | RECTANGULAR |
| Package Style | SMALL OUTLINE |
| Peak Reflow Temperature (Cel) | 235 |
| Power Supplies (V) | 5 |
| Qualification Status | Not Qualified |
| Receive Delay-Max | 40.0 ns |
| Receiver Number of Bits | 1.0 |
| Seated Height-Max | 1.75 mm |
| Sub Category | Line Driver or Receivers |
| Supply Current-Max | 2.2 mA |
| Supply Voltage-Nom | 5.0 V |
| Supply Voltage-Min | 4.75 V |
| Supply Voltage-Max | 5.25 V |
| Surface Mount | YES |
| Technology | BICMOS |
| Temperature Grade | INDUSTRIAL |
| Terminal Finish | Tin/Lead (Sn85Pb15) |
| Terminal Form | GULL WING |
| Terminal Pitch | 1.27 mm |
| Terminal Position | DUAL |
| Time@Peak Reflow Temperature-Max (s) | 20 |
| Transmit Delay-Max | 15.0 ns |
| Length | 4.9 mm |
| Width | 3.9 mm |
| Additional Feature | 1 RECEIVER ACTIVE UNDER SHUTDOWN; COMMON I/O; TRISTATABLE RECEIVERS |
