(5PCS) 747238-4 AMP D Subminiature Connector, 25 Contact #4/40 Unc, Plug
Tax included.
This listing is for (5PCS) of 747238-4 by AMP
Status Discontinued
Additional Feature AMPLIMITE
Board Mounting Option SPLIT BOARD LOCK
Body Breadth (inch) 0.494000
Body Depth (inch) 0.508000
Body Length (inch) 2.080000
Body/Shell Style PLUG
Connector Type D SUBMINIATURE CONNECTOR
Contact Design PREASSEM CONN
Contact Finish - Mating NOT APPLICABLE
Contact Finish - Termination Tin/Lead (Sn/Pb) - with Nickel (Ni) barrier
Contact Gender MALE
Contact Material NOT APPLICABLE
Contact Pattern STAGGERED
Contact Resistance (mohm) 20.000000000000000
Contact Style RND PIN-SKT
DIN Conformance NO
EMI Shielded NO
Empty Shell YES
Filter Feature NO
IEC Conformance NO
Insertion Force-Max (N) 2.224
Insulation Resistance (ohm) 1000000000.000000000000000
Insulator Color BLACK
Insulator Material POLYETHYLENE
J-STD-609 Code e0
MIL Conformance NO
Mains Connector Rating 6A
Mating Contact Pitch (inch) 0.109
Mating Contact Row Spacing (inch) 0.112
Mating Information MULTIPLE MATING PARTS AVAILABLE
Mixed Contacts NO
Mounting Option 1 #4/40 UNC
Mounting Option 2 THREADED INSERT
Mounting Style RIGHT ANGLE
Mounting Type BOARD
Number of Connectors ONE
Number of PCB Rows 2
Number of Ports 1
Number of Rows Loaded 2
Operating Temperature-Max (Cel) 105
Operating Temperature-Min (Cel) -55
Option GENERAL PURPOSE
PCB Contact Pattern STAGGERED
PCB Contact Row Spacing (mm) 2.84
Panel Mount NO
Plating Thickness (inch) 30u
Rated Current (Signal) (A) 6.0000000000000000
Screening Level / Reference Standard UL
Shell Finish TIN
Shell Material ZINC ALLOY
Shell Size 3/B
Terminal Length (inch) 0.125000
Terminal Pitch (mm) 2.76
Termination Type SOLDER
Number of Contacts 25
UL Flammability Code 94V-0
Withdrawl Force-Min (N) 2.224
