(2 PCS) 71V256SA15Y IDT SRAM Chip Async Single 3.3V 256K-Bit 32K x 8 15ns SOJ-28
Tax included.
THIS LISTING IS FOR (5 PCS) OF 71V256SA15Y BY IDT
SRAM Chip Async Single 3.3V 256K-Bit 32K x 8 15ns SOJ-28
The IDT71V256SA is a 262,144-bit high-speed static RAM organizedas 32K x 8. It is fabricated using a high-performance, high-reliabilityCMOS technology. The IDT71V256SA has outstanding low power characteristics whileat the same time maintaining very high performance. Address accesstimes of as fast as 12ns are ideal for 3.3V secondary cache in 3.3Vdesktop designs. The IDT71V256SA is packaged in a 28-pin 300 mil SOJ and a 28-pin300 mil TSOP Type I.
Key Features
Ideal for high-performance processor secondary cache
Commercial (0°C to +70°C) and Industrial (–40°C to +85°C) temperature range options
Fast access times:
Commercial and Industrial: 12/15/20ns
Low standby current (maximum):
2mA full standby
Small packages for space-efficient layouts:
28-pin 300 mil SOJ
28-pin TSOP Type I
Produced with advanced high-performance CMOS technology
Inputs and outputs are LVTTL-compatible
Single 3.3V(±0.3V) power supply
Address Bus Width 15 Bit
Density 256 Kb
Lead Finish Tin/Lead
Max Processing Temp 225
Maximum Operating Current 85 mA
Maximum Operating Supply Voltage 3.6 V
Maximum Random Access Time 15 ns
Minimum Operating Supply Voltage 3 V
Mounting Surface Mount
Number of Bits per Word 8 Bit
Number of I/O Lines 8 Bit
Number of Ports 1
Number of Words 32 kWords
Operating Temperature 0 to 70 °C
Pin Count 28
Product Dimensions 17.9 x 7.6 x 2.41 mm
Screening Level Commercial
Supplier Package SOJ
Timing Type Asynchronous
Typical Operating Supply Voltage 3.3000 V
ECCN / UNSPSC / COO
