(5PCS) 11DQ04 Schottky Diodes & Rectifiers 1.1 Amp 40 Volt
Tax included.
THIS LISTING IS FOR (5 PCS) OF 11DQ04 BY INTERNATIONAL RECTIFIER
11DQ04 Part Details & Parametric
|
|
|
| Minimum Operating Temperature (°C) | -40 |
| Maximum Operating Temperature (°C) | 150 |
| Type | Schottky Diode |
| Peak Reverse Current (uA) | 1000 |
| Configuration | Single |
| Packaging | Box |
| Peak Reverse Repetitive Voltage (V) | 40 |
| Maximum Continuous Forward Current (A) | 1.1 |
| Peak Forward Voltage (V) | 0.71@2A |
| Peak Non-Repetitive Surge Current (A) | 225 |
| Operating Junction Temperature (°C) | -40 to 150 |
| Package Diameter (mm) | 2.7(Max) |
| Mounting | Through Hole |
| Package Length (mm) | 5.21(Max) |
| PCB | 2 |
| Standard Package Name | DO-41 |
| Supplier Package | DO-204AL |
| Pin Count | 2 |
| Lead Shape | Through Hole |
