(5pcs) 0313005.MXP Littelfuse Cartridge Fuses 250V 5A Slo-Blo
Tax included.
THIS LISTING IS FOR (5PCS) OF 0313005.MXP BY LITTELFUSE
REACH Compliant Yes
EU RoHS Compliant Yes
China RoHS Compliant Yes
Status Active
Circuit Protection Type ELECTRIC FUSE
Blow Characteristic TIME LAG
Body Height 31.75 mm
Body Length or Diameter 6.35 mm
Fuse Class Supplemental
Fuse Size 3AG
Joule-integral-Nom 276.0 J
Mounting Feature INLINE/HOLDER
Operating Temperature-Min -60.0 Cel
Operating Temperature-Max 125.0 Cel
Packing Method BULK
Physical Dimension 6.35mm x 31.75mm
Rated Breaking Capacity 200.0 A
Rated Current 5.0 A
Rated Voltage 250.0 V
Reference Standard CE; CSA; KC; PSE; UL
Terminal Finish NICKEL
Terminal Shape END CAP
Trip Time or Delay 5.0 Seconds
