(5PC) EKZE100ETE222MK20S Electrolytic Capacitor 2200µF 10V 20% 105°C Radial ROHS
Tax included.
THIS LISTING IS FOR (5 PCS) OF EKZE100ETE222MK20S BY NIPPON
Electrolytic Capacitor 2200µF 10V 20% 105°C Radial ROHS
Manufacturer United Chemi-Con (Nippon Chemi-Con)
Series KZE
Packaging Tape & Box (TB)
Part Status Active
Capacitance 2200µF
Tolerance ±20%
Voltage - Rated 10V
ESR (Equivalent Series Resistance) -
Lifetime @ Temp. 5000 Hrs @ 105°C
Operating Temperature -40°C ~ 105°C
Polarization Polar
Ratings -
Applications General Purpose
Ripple Current @ Low Frequency 1.77A @ 120Hz
Ripple Current @ High Frequency 2.36A @ 100kHz
Impedance 21 mOhms
Lead Spacing 0.197" (5.00mm)
Size / Dimension 0.492" Dia (12.50mm)
Height - Seated (Max) 0.846" (21.50mm)
Surface Mount Land Size -
Mounting Type Through Hole
Package / Case Radial, Can
