(50PCS) SK225LD LITTELFUSE SCR 1.2 kV 25 A Standard Recovery Through TO-220AB
(50PCS) SK225LD LITTELFUSE SCR 1.2 kV 25 A Standard Recovery Through TO-220AB
(50PCS) SK225LD LITTELFUSE SCR 1.2 kV 25 A Standard Recovery Through TO-220AB
(50PCS) SK225LD LITTELFUSE SCR 1.2 kV 25 A Standard Recovery Through TO-220AB
(50PCS) SK225LD LITTELFUSE SCR 1.2 kV 25 A Standard Recovery Through TO-220AB
(50PCS) SK225LD LITTELFUSE SCR 1.2 kV 25 A Standard Recovery Through TO-220AB
(50PCS) SK225LD LITTELFUSE SCR 1.2 kV 25 A Standard Recovery Through TO-220AB

(50PCS) SK225LD LITTELFUSE SCR 1.2 kV 25 A Standard Recovery Through TO-220AB

Tax included.
Only 5 left!
THIS LISTING IS FOR (50PCS) OF SK225LDTP BY LITTELFUSE

Specifications
Product Attribute Attribute Value Search Similar
Manufacturer: Littelfuse
Product Category: SCRs
RoHS:  Details
Series: SK225xD
Rated Repetitive Off-State Voltage VDRM: 1.2 kV
Off-State Leakage Current @ VDRM IDRM: 10 uA
On-State RMS Current - It RMS: 25 A
Vf - Forward Voltage: 1.6 V
Gate Trigger Voltage - Vgt: 1.5 V
Gate Trigger Current - Igt: 40 mA
Holding Current Ih Max: 100 mA
Minimum Operating Temperature: - 40 C
Maximum Operating Temperature: + 125 C
Mounting Style: Through Hole
Package / Case: TO-220-2
Packaging: Tube
Brand: Littelfuse
Non Repetitive On-State Current: 360 A
Product Type: SCRs
Factory Pack Quantity: 1000
Subcategory: Thyristors
Tradename: Teccor
