(50PCS) QK006NH4TP LITTELFUSE TRIAC ALTERNISTOR 1KV 6A TO263
Tax included.
THIS LISTING IS FOR (50PCS) OF QK006NH4TP BY LITTELFUSE
SPECIFICATIONS
| Mfr Package Description | ROHS COMPLIANT, PLASTIC, D2PAK-3/2 |
| EU RoHS Compliant | Yes |
| Status | Active |
| Trigger Device Type | ALTERNISTOR TRIAC |
| Case Connection | MAIN TERMINAL 2 |
| Configuration | SINGLE |
| Critical Rate of Rise of Commutation Voltage-Min | 25.0 V/us |
| Critical Rate of Rise of Off-state Voltage-Min | 150.0 V/us |
| DC Gate Trigger Current-Max | 35.0 mA |
| DC Gate Trigger Voltage-Max | 1.3 V |
| Holding Current-Max | 35.0 mA |
| JEDEC-95 Code | TO-263AB |
| JESD-30 Code | R-PSSO-G2 |
| JESD-609 Code | e3 |
| Leakage Current-Max | 2.0 mA |
| Number of Elements | 1.0 |
| Number of Terminals | 2 |
| Operating Temperature-Min | -40.0 Cel |
| Operating Temperature-Max | 125.0 Cel |
| Package Body Material | PLASTIC/EPOXY |
| Package Shape | RECTANGULAR |
| Package Style | SMALL OUTLINE |
| Peak Reflow Temperature (Cel) | NOT SPECIFIED |
| Qualification Status | Not Qualified |
| Repetitive Peak Off-state Voltage | 1000.0 V |
| RMS On-state Current-Max | 6.0 A |
| Sub Category | TRIACs |
| Surface Mount | YES |
| Terminal Finish | Matte Tin (Sn) |
| Terminal Form | GULL WING |
| Terminal Position | SINGLE |
| Time@Peak Reflow Temperature-Max (s) | NOT SPECIFIED |
| Additional Feature | HIGH RELIABILITY |
