(50PC) ZRT040GA1TA Three Terminal Voltage Reference 1 Output 2.5V SOT-223-4 ROHS
Tax included.
THIS IS FOR (50 PCS) OF ZRT040GA1TA BY ZETEX
Three Terminal Voltage Reference 1 Output 2.5V SOT-223-4 ROHS
Part #: ZRT025GA1TA
Part Category: Voltage References
Manufacturer: ZETEX PLC
Description: Three Terminal Voltage Reference, 1 Output, 2.5V, Trim/Adjustable, PDSO4
Status Transferred
Analog IC - Other Type THREE TERMINAL VOLTAGE REFERENCE
JESD-30 Code R-PDSO-G4
J-STD-609 Code e3
Length (mm) 6.5000
Moisture Sensitivity Level 1
Number of Functions 1
Number of Outputs 1
Number of Terminals 4
Operating Temperature-Max (Cel) 125
Operating Temperature-Min (Cel) -55
Output Voltage-Max (V) 2.5250000000000000
Output Voltage-Min (V) 2.4750000000000000
Output Voltage-Nom (V) 2.5000000000000000
Package Body Material PLASTIC/EPOXY
Package Code LSOP
Package Equivalence Code SOT-223
Package Shape RECTANGULAR
Package Style SMALL OUTLINE, LOW PROFILE
Peak Reflow Temperature (Cel) 260
DLA Qualification Not Qualified
Seated Height-Max (mm) 1.7000
Supply Current-Max (mA) 75.0000000000000000
Surface Mount YES
Temp Coef of Voltage-Max (ppm/Cel) 50.0000000000000000
Temperature Grade MILITARY
Terminal Finish Matte Tin (Sn)
Terminal Form GULL WING
Terminal Pitch (mm) 2.300
Terminal Position DUAL
Time@Peak Reflow Temperature-Max (s) 40
Trim/Adjustable Output YES
Voltage Tolerance-Max (%) 1.000000
Width (mm) 3.5000
