(50 PCS) SB160-T DIODES INC Diode Schottky 60V 1A 2-Pin DO-41 T/R
Tax included.
THIS LISTING IS FOR (50 PCS) OF SB160-T BY DIODES INC
(50 PCS) SB160-T DIODES INC
Diode Schottky 60V 1A 2-Pin DO-41 T/R
(50 PCS) SB160-T DIODES INC
Diode Schottky 60V 1A 2-Pin DO-41 T/R
SB160-T Part Details & Parametric
| EU RoHS | Compliant |
| Minimum Operating Temperature (°C) | -65 |
| Maximum Operating Temperature (°C) | 150 |
| Type | Schottky Diode |
| Peak Reverse Current (uA) | 500 |
| Configuration | Single |
| Packaging | Tape and Reel |
| Peak Reverse Repetitive Voltage (V) | 60 |
| Maximum Continuous Forward Current (A) | 1 |
| Peak Forward Voltage (V) | 0.7 |
| Peak Non-Repetitive Surge Current (A) | 40 |
| Operating Junction Temperature (°C) | -65 to 150 |
| Package Diameter (mm) | 2.72(Max) |
| Mounting | Through Hole |
| Package Length (mm) | 5.21(Max) |
| PCB | 2 |
| Standard Package Name | DO-204-AL |
| Supplier Package | DO-41 |
| Pin Count | 2 |
| Lead Shape | Through Hole |
