(50 PCS) L6917BDTR STMICRO 5 BIT PROGRAMMABLE DUAL-PHASE CONTROLLER ROHS
Tax included.
THIS IS FOR (50 PCS) OF L6917BDTR BY STMICRO
5 BIT PROGRAMMABLE DUAL-PHASE CONTROLLER ROHS
Part #: L6917BDTR
Obsolete
Part Category: Switching Regulator or Controllers
Manufacturer: STMICROELECTRONICS
Description:
Switching Controller, Current-mode, 600kHz Switching Freq-Max, BCDMOS, PDSO28
Status Discontinued
Analog IC - Other Type SWITCHING CONTROLLER
Control Mode CURRENT-MODE
Control Technique PULSE WIDTH MODULATION
Input Voltage-Max (V) 12.1000000000000000
Input Voltage-Min (V) 11.9000000000000000
Input Voltage-Nom (V) 12
JESD-30 Code R-PDSO-G28
J-STD-609 Code e4
Length (mm) 17.9000
Number of Functions 1
Number of Terminals 28
Operating Temperature-Max (Cel) 70
Operating Temperature-Min (Cel) 0
Package Body Material PLASTIC/EPOXY
Package Code SOP
Package Equivalence Code SOP28,.4
Package Shape RECTANGULAR
Package Style SMALL OUTLINE
DLA Qualification Not Qualified
Screening Level / Reference Standard ATEX
Seated Height-Max (mm) 2.6500
Supply Current-Max (mA) 12.5000000000000000
Surface Mount YES
Switcher Configuration PHASE-SHIFT
Switching Frequency-Max (kHz) 600.0000000000000000
Technology BCDMOS
Temperature Grade COMMERCIAL
Terminal Finish NICKEL PALLADIUM GOLD
Terminal Form GULL WING
Terminal Pitch (mm) 1.270
Terminal Position DUAL
Width (mm) 7.5000
