(50 PCS) IRF40B207 IR N-Channel 40V 95A (Tc) 83W (Tc) TO-220AB ROHS
(50 PCS) IRF40B207 IR N-Channel 40V 95A (Tc) 83W (Tc) TO-220AB ROHS
(50 PCS) IRF40B207 IR N-Channel 40V 95A (Tc) 83W (Tc) TO-220AB ROHS

(50 PCS) IRF40B207 IR N-Channel 40V 95A (Tc) 83W (Tc) TO-220AB ROHS

Tax included.
Only 90 left!
THIS LISTING IS FOR (50 PCS) OF IRF40B207 BY IR
N-Channel 40V 95A (Tc) 83W (Tc) TO-220AB ROHS

Manufacturer: Infineon (IR)
Product Category: MOSFET
RoHS:  Y
Technology: Si
Mounting Style: Through Hole
Package / Case: TO-220-3
Transistor Polarity: N-Channel
Number of Channels: 1 Channel
Vds - Drain-Source Breakdown Voltage: 40 V
Id - Continuous Drain Current: 95 A
Rds On - Drain-Source Resistance: 3.6 mOhms
Vgs - Gate-Source Voltage: - 20 V, + 20 V
Vgs th - Gate-Source Threshold Voltage: 2.2 V
Qg - Gate Charge: 68 nC
Minimum Operating Temperature: - 55 C
Maximum Operating Temperature: + 175 C
Pd - Power Dissipation: 83 W
Channel Mode: Enhancement
Tradename: StrongIRFET
Packaging: Tube
Configuration: Single
Height: 15.65 mm
Length: 10 mm
Transistor Type: 1 N-Channel
Width: 4.4 mm
Brand: Infineon / IR
Forward Transconductance - Min: 170 S
Fall Time: 19 ns
Product Type: MOSFET
Rise Time: 35 ns
Factory Pack Quantity: 50
Subcategory: MOSFETs
Typical Turn-Off Delay Time: 25 ns
Typical Turn-On Delay Time: 7.8 ns
Part # Aliases: IRF40B207 SP001564728
Unit Weight: 0.068784 oz
