(50 PCS) AM29LV017D-90WCC AMD Flash, 2MX8, 90ns, TFBGA48
Tax included.
THIS LISTING IS FOR (50 PCS) OF AM29LV017D-90WCC BY AMD
Flash, 2MX8, 90ns, TFBGA48
Part #: AM29LV017D-90WCC
Part Category: Memory ICs
Manufacturer: Advanced Micro Devices, Inc.
Description: Flash, 2MX8, 90ns, PBGA48
Mfr Package Description 8 X 9 MM, 0.80 MM PITCH, FBGA-48
Status Transferred
Type NOR TYPE
Sub Category Flash Memories
Access Time-Max 90.0 ns
Command User Interface YES
Common Flash Interface YES
Data Polling YES
JESD-30 Code R-PBGA-B48
JESD-609 Code e0
Memory Density 1.6777216E7 bit
Memory IC Type FLASH
Memory Width 8
Number of Functions 1
Number of Sectors/Size 32
Number of Terminals 48
Number of Words 2097152.0 words
Number of Words Code 2M
Operating Mode ASYNCHRONOUS
Operating Temperature-Min 0.0 Cel
Operating Temperature-Max 70.0 Cel
Organization 2MX8
Package Body Material PLASTIC/EPOXY
Package Code TFBGA
Package Equivalence Code BGA48,6X8,32
Package Shape RECTANGULAR
Package Style GRID ARRAY, THIN PROFILE, FINE PITCH
Parallel/Serial PARALLEL
Qualification Status Not Qualified
Ready/Busy YES
Seated Height-Max 1.2 mm
Standby Current-Max 5.0E-6 Amp
Supply Current-Max 0.03 Amp
Supply Voltage-Nom (Vsup) 3.0 V
Supply Voltage-Min (Vsup) 2.7 V
Supply Voltage-Max (Vsup) 3.6 V
Surface Mount YES
Technology CMOS
Temperature Grade COMMERCIAL
Terminal Finish Tin/Lead (Sn/Pb)
Terminal Form BALL
Terminal Pitch 0.8 mm
Terminal Position BOTTOM
Toggle Bit YES
Length 9.0 mm
Width 8.0 mm
