(5) TX25-80P-12ST-N1 JAE Board to Board & Mezzanine Connectors 80P plug Straight
Tax included.
THIS IS FOR (5 PCS) OF TX25-80P-12ST-N1 BY JAE
Board to Board & Mezzanine Connectors 80P plug Straight
Part #: TX25-80P-12ST-N1
Obsolete
Part Category: Headers and Edge Type Connectors
Manufacturer: JAPAN AVIATION ELECTRONICS INDUSTRY LTD
Description:
Board Stacking Connector, 80 Contact(s), 2 Row(s), Male, Straight, 0.05 inch Pitch, Solder Terminal, Black Insulator, Receptacle
Status Discontinued
Additional Feature POLARIZED
Body Breadth (inch) 0.315000
Body Depth (inch) 0.598000
Body Length (inch) 2.496000
Body/Shell Style RECEPTACLE
Connector Type BOARD STACKING CONNECTOR
Contact Finish - Mating NOT SPECIFIED
Contact Gender MALE
Contact Material NOT SPECIFIED
Contact Pattern RECTANGULAR
Contact Resistance (mohm) 40.000000000000000
DIN Conformance NO
Dielectric Withstanding Voltage (V) 500VAC
Filter Feature NO
IEC Conformance NO
Insulation Resistance (ohm) 100000000.000000000000000
Insulator Color BLACK
Insulator Material POLYBUTYLENE TEREPHTHALATE
MIL Conformance NO
Mating Contact Pitch (inch) 0.05
Mating Information MULTIPLE MATING PARTS AVAILABLE
Mixed Contacts NO
Mounting Style STRAIGHT
Mounting Type BOARD
Number of Connectors ONE
Number of PCB Rows 4
Number of Rows Loaded 2
Operating Temperature-Max (Cel) 80
Operating Temperature-Min (Cel) -40
Option GENERAL PURPOSE
PCB Contact Pattern STAGGERED
PCB Contact Row Spacing (mm) 1.905
Plating Thickness (inch) 4u
Polarization Key POLARIZED KEY
Rated Current (Signal) (A) 1.0000000000000000
Screening Level / Reference Standard UL
Terminal Length (inch) 0.110000
Terminal Pitch (mm) 2.54
Termination Type SOLDER
Number of Contacts 80
UL Flammability Code 94V-0
