(5 PCS) ZRA250N803 DIODES INC. Voltage Reference 1 Output 2.5V BIPolar SOIC-8

$8.95
Unit price per

Tax included.

THIS IS FOR (5 PCS) OF ZRA250N803 BY DIODES INC.

Voltage Reference 1 Output 2.5V BIPolar SOIC-8

Part #: ZRA250N803

Part Category: Other Semiconductors

Manufacturer: DIODES Incorporated

Description: Two Terminal Voltage Reference, 1 Output, 2.5V, BIPolar, PDSO8

Mfr Package Description SOP-8

REACH Compliant Yes

Status Discontinued

Analog IC - Other Type TWO TERMINAL VOLTAGE REFERENCE

JESD-30 Code R-PDSO-G8

Number of Functions 1

Number of Outputs 1.0

Number of Terminals 8

Operating Temperature-Min -40.0 Cel

Operating Temperature-Max 85.0 Cel

Output Voltage-Nom 2.5 V

Output Voltage-Min 2.425 V

Output Voltage-Max 2.575 V

Package Body Material PLASTIC/EPOXY

Package Code SOP

Package Equivalence Code SOP8,.25

Package Shape RECTANGULAR

Package Style SMALL OUTLINE

Qualification Status Not Qualified

Seated Height-Max 1.75 mm

Sub Category Voltage References

Surface Mount YES

Technology BIPOLAR

Temp Coef of Voltage-Max 90.0 ppm/Cel

Temperature Grade INDUSTRIAL

Terminal Form GULL WING

Terminal Pitch 1.27 mm

Terminal Position DUAL

Voltage Tolerance-Max 3.0 %

Length 4.89 mm

Width 3.9 mm
