(5 PCS) VN2450N8 SUPERTEX MOSFET N-CH 500V 0.25A 3-Pin SOT-89 T/R ROHS
(5 PCS) VN2450N8 SUPERTEX MOSFET N-CH 500V 0.25A 3-Pin SOT-89 T/R ROHS
(5 PCS) VN2450N8 SUPERTEX MOSFET N-CH 500V 0.25A 3-Pin SOT-89 T/R ROHS

(5 PCS) VN2450N8 SUPERTEX MOSFET N-CH 500V 0.25A 3-Pin SOT-89 T/R ROHS

Tax included.
Only 44 left!
THIS IS FOR (5 PCS) OF VN2450N8 BY SUPERTEX
MOSFET N-CH 500V 0.25A 3-Pin SOT-89 T/R

Part #: VN2450N8
Obsolete
Part Category: Power Field-Effect Transistors
Manufacturer: SUPERTEX INC
Description:
Power Field-Effect Transistor, 0.25A I(D), 500V, 13ohm, 1-Element, N-Channel, Silicon, Metal-oxide Semiconductor FET, TO-243AA
Status Discontinued
Additional Feature LOW THRESHOLD
Case Connection DRAIN
Configuration SINGLE WITH BUILT-IN DIODE
DS Breakdown Voltage-Min (V) 500.0000000000000000
Drain Current-Max (ID) (A) 0.2500000000000000
Drain-source On Resistance-Max (ohm) 13.0000000000000000
FET Technology METAL-OXIDE SEMICONDUCTOR
JEDEC-95 Code TO-243AA
JESD-30 Code R-PSSO-F3
J-STD-609 Code e0
Number of Elements 1
Number of Terminals 3
Operating Mode ENHANCEMENT MODE
Operating Temperature-Max (Cel) 150
Package Body Material PLASTIC/EPOXY
Package Shape RECTANGULAR
Package Style SMALL OUTLINE
Polarity/Channel Type N-CHANNEL
Power Dissipation-Max (W) 1.600000000000000
Pulsed Drain Current-Max (IDM) (A) 0.7500000000000000
DLA Qualification Not Qualified
Surface Mount YES
Terminal Finish TIN LEAD
Terminal Form FLAT
Terminal Position SINGLE
Application SWITCHING
Transistor Element Material SILICON
