(5 PCS) UPD70116L-8 NEC Microprocessor, 16-Bit, 8MHz, CMOS, PLCC44

THIS IS FOR (5 PCS) OF UPD70116L-8 BY NEC

Mfr Package Description PLASTIC, LCC-44

REACH Compliant Yes

Status Discontinued

Address Bus Width 20.0

Bit Size 16

Boundary Scan NO

Clock Frequency-Max 8.0  MHz

External Data Bus Width 16.0

Format FIXED POINT

Integrated Cache NO

JESD-30 Code S-PQCC-J44

JESD-609 Code e0

Low Power Mode YES

Number of DMA Channels 0.0

Number of External Interrupts 2.0

Number of Serial I/Os 0.0

Number of Terminals 44

On Chip Data RAM Width 0

Operating Temperature-Min -10.0  Cel

Operating Temperature-Max 70.0  Cel

Package Body Material PLASTIC/EPOXY

Package Code QCCJ

Package Shape SQUARE

Package Style CHIP CARRIER

Qualification Status Not Qualified

RAM (words) 0

Seated Height-Max 4.6  mm

Speed 8.0  MHz

Supply Current-Max 80.0  mA

Supply Voltage-Nom 5.0  V

Supply Voltage-Min 4.75  V

Supply Voltage-Max 5.25  V

Surface Mount YES

Technology CMOS

Temperature Grade COMMERCIAL

Terminal Finish TIN LEAD

Terminal Form J BEND

Terminal Pitch 1.27  mm

Terminal Position QUAD

Length 16.5862  mm

Width 16.5862  mm
