(5 PCS) TSL1110-221KR68 TDK Bobbin Wound High Current Inductor 220uH 10% Radial
Tax included.
THIS LISTING IS FOR (5 PCS) OF TSL1110-221KR68 BY TDK
Bobbin Wound High Current Inductor 220uH 10% Radial
Part #: TSL1110-221KR68
Part Category: Inductors
Manufacturer: TDK Corporation
Description: General Purpose Inductor, 220uH, 10%, 1 Element
Status Discontinued
Inductor Type GENERAL PURPOSE INDUCTOR
Construction Bobbin Wound
DC Resistance 0.25 ohm
Inductance-Nom (L) 220.0 µH
Inductor Application HIGH CURRENT INDUCTOR
Number of Functions 1
Number of Terminals 2
Operating Temperature-Min -20.0 Cel
Operating Temperature-Max 85.0 Cel
Package Diameter 11.5 mm
Package Length 10.5 mm
Quality Factor-Min (at L-nom) 20.0
Rated Current-Max 0.77 A
Self Resonance Frequency 2.5 MHz
Series TSL
Shape/Size Description CYLINDRICAL PACKAGE
Shielded NO
Special Feature Q MEASURED AT 796 KHZ
Surface Mount NO
Terminal Placement RADIAL
Terminal Shape PRINTED WIRING PIN
Test Frequency 0.001 MHz
Tolerance 10.0 %
