(5 PCS) STS9NF30L ST MICRO MOSFET N-CH 30V 9A 8-SOIC ROHS
Tax included.
THIS LISTING IS FOR (5 PCS) OF STS9NF30L BY ST MICRO
MOSFET N-CH 30V 9A 8-SOIC ROHS
Manufacturer: STMicroelectronics
Product Category: MOSFET
RoHS: Yes
Technology: Si
Mounting Style: SMD/SMT
Package / Case: SOIC-8
Transistor Polarity: N-Channel
Number of Channels: 1 Channel
Vds - Drain-Source Breakdown Voltage: 30 V
Id - Continuous Drain Current: 9 A
Rds On - Drain-Source Resistance: 15 mOhms
Vgs - Gate-Source Voltage: - 18 V, + 18 V
Minimum Operating Temperature: - 55 C
Maximum Operating Temperature: + 150 C
Pd - Power Dissipation: 2.5 W
Channel Mode: Enhancement
Packaging: Cut Tape
Packaging: MouseReel
Packaging: Reel
Configuration: Single
Height: 1.65 mm
Length: 5 mm
Series: STS9NF30L
Transistor Type: 1 N-Channel
Type: Power MOSFET
Width: 4 mm
Brand: STMicroelectronics
Forward Transconductance - Min: 13 S
Fall Time: 24 ns
Product Type: MOSFET
Rise Time: 80 ns
Factory Pack Quantity: 2500
Subcategory: MOSFETs
Typical Turn-Off Delay Time: 38 ns
Typical Turn-On Delay Time: 15 ns
