(5 PCS) SP-1511S SOBERTON SPEAKER 8OHM 700MW TOP PORT 83DB SPRING TYPE
Tax included.
THIS IS FOR (5 PCS) OF SP-1511S BY SOBERTON
SPEAKER 8OHM 700MW TOP PORT 83DB SPRING TYPE
Mfr Soberton Inc.
Series SP Micro Speaker
Package Tray
Product Status Active
Technology Magnetic
Type General Purpose
Frequency Range 200 Hz ~ 3.4 kHz
Frequency - Self Resonant 850Hz
Impedance 8 Ohms
Efficiency - dBA 83.00
Efficiency - Testing 100mW
Efficiency - Type Sound Pressure Level (SPL)
Power - Rated 700 mW
Power - Max 1 W
Port Location Top
Shape Rectangular
Material - Cone -
Material - Magnet Nd-Fe-B
Ingress Protection -
Ratings -
Termination Spring Type
Size / Dimension 0.591" L x 0.433" W (15.00mm x 11.00mm)
Height - Seated (Max) 0.177" (4.50mm)
