(5 PCS) SN74S20N TI NAND Gate 2-Element 4-IN Bipolar 14-Pin PDIP
Tax included.
THIS LISTING IS FOR (5 PCS) OF 74S20N BY SIG
NAND Gate 2-Element 4-IN Bipolar 14-Pin PDIP
Manufacturer Signetics
Series 74S
Packaging Tube
Part Status Active
Logic Type NAND Gate
Number of Circuits 2
Number of Inputs 4
Features -
Voltage - Supply 4.75V ~ 5.25V
Current - Quiescent (Max) 8mA
Current - Output High, Low 1mA, 20mA
Logic Level - Low 0.8V
Logic Level - High 2V
Max Propagation Delay @ V, Max CL 5ns @ 5V, 50pF
Operating Temperature 0°C ~ 70°C
Mounting Type Through Hole
Supplier Device Package 14-PDIP
Package / Case 14-DIP (0.300", 7.62mm)
Base Part Number 74S20
