(5 pcs) SN74S11N AND Gate, S Series, 3-Func, 3-Input, TTL, PDIP14
Tax included.
THIS LISTING IS FOR (5PCS) OF SN74S11N BY TEXAS INSTRUMENTS
Mfr Package Description PLASTIC, DIP-14
Status Discontinued
Logic IC Type AND GATE
Sub Category Gates
Family S
JESD-30 Code R-PDIP-T14
Load Capacitance (CL) 15.0 pF
Max I(ol) 0.02 Amp
Number of Functions 3
Number of Inputs 3.0
Number of Terminals 14
Operating Temperature-Min 0.0 Cel
Operating Temperature-Max 70.0 Cel
Package Body Material PLASTIC/EPOXY
Package Code DIP
Package Equivalence Code DIP14,.3
Package Shape RECTANGULAR
Package Style IN-LINE
Peak Reflow Temperature (Cel) NOT SPECIFIED
Power Supply Current-Max (ICC) 42.0 mA
Prop. Delay@Nom-Sup 7.5 ns
Propagation Delay (tpd) 7.5 ns
Qualification Status Not Qualified
Schmitt Trigger NO
Seated Height-Max 5.08 mm
Supply Voltage-Nom (Vsup) 5
Supply Voltage-Min (Vsup) 4.75 V
Supply Voltage-Max (Vsup) 5.25 V
Surface Mount NO
Technology TTL
Temperature Grade COMMERCIAL
Terminal Form THROUGH-HOLE
Terminal Pitch 2.54 mm
Terminal Position DUAL
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Length 19.305 mm
Width 7.62 mm
