(5 PCS) S2025NRP TECCOR SCR NON-SENS 200V 25A TO-263
Tax included.
THIS LISTING IS FOR (5 PCS) OF S2025NRP BY TECCOR
SCR NON-SENS 200V 25A TO-263
Manufacturer:
SCR NON-SENS 200V 25A TO-263
Manufacturer:
| Littelfuse | ||
| Product Category: | SCRs | |
| Breakover Current IBO Max: | 350 A | |
| Rated Repetitive Off-State Voltage VDRM: | 200 V | |
| Off-State Leakage Current @ VDRM IDRM: | 0.01 mA | |
| On-State RMS Current - It RMS: | 10 A | |
| Vf - Forward Voltage: | 1.6 V | |
| Gate Trigger Voltage - Vgt: | 1.5 V | |
| Gate Trigger Current - Igt: | 35 mA | |
| Holding Current Ih Max: | 50 mA | |
| Mounting Style: | SMD/SMT | |
| Package / Case: | TO-263 | |
| Packaging: | Reel | |
| Brand: | Littelfuse |
|
| Current Rating: | 10 A |
|
| Features: | Glass passivated Chip junction |
|
| Height: | 4.78 mm (Max) |
|
| Length: | 10.67 mm (Max) |
|
| Maximum Operating Temperature: | + 125 C |
|
| Minimum Operating Temperature: | - 40 C |
|
| Non Repetitive On-State Current: | 350 A |
