(5 PCS) RL110-101K MILLER 100µH Unshielded Wirewound Inductor 1.7A 160mOhm 10%
Tax included.
THIS LISTING IS FOR (5 PCS) OF RL110-101K BY JW MILLER
100µH Unshielded Wirewound Inductor 1.7A 160mOhm 10%
Manufacturer JW Miller/Bourns Inc.
Series RL110
Packaging Bulk
Part Status Obsolete
Type Wirewound
Material - Core Ferrite
Inductance 100µH
Tolerance ±10%
Current Rating (Amps) 1.7A
Current - Saturation -
Shielding Unshielded
DC Resistance (DCR) 160mOhm Max
Q @ Freq -
Frequency - Self Resonant 5.7MHz
Ratings -
Operating Temperature -30°C ~ 100°C
Inductance Frequency - Test 1kHz
Mounting Type Through Hole
Package / Case Radial, Vertical Cylinder, 4 Leads (Open)
Supplier Device Package -
Size / Dimension 0.394" Dia (10.00mm)
Height - Seated (Max) 0.394" (10.00mm)
