(5 PCS) PS-05-5 MEANWELL Switching Power Supplies 5W 5V 1A ROHS

  • $32.95
    Unit price per
Tax included.

Only 40 left!

THIS LISTING IS FOR (5 PCS) OF PS-05-5 BY MEANWELL
Switching Power Supplies 5W 5V 1A ROHS
EU RoHS Compliant
ECCN (US) EAR99
Part Status Active
Type Switching
Style Open Frame
Input/Output Type AC/DC
Number of Outputs 1
Output Type Fixed
Output Voltage (V) 5
Output Current (A) 1.2
Output Power (W) 5
Minimum AC Input Voltage (V) 85
Maximum AC Input Voltage (V) 264
Minimum DC Input Voltage (V) 120
Maximum DC Input Voltage (V) 370
Minimum Isolation Voltage 3000VAC
Line Regulation 1%
Load Regulation 1%
Maximum Input Current (A) 0.15(Typ)
Input Frequency (Hz) 47 to 63
Tolerance (%) ±2
Efficiency (%) 70(Typ)
Configurable No
Input Connector Type Pin Terminal Block
Output Connector Type Pin Terminal Block
Power Indicator No
Ripple & Noise 100mV(Max)
Medical No
Minimum Operating Temperature (°C) -10
Maximum Operating Temperature (°C) 60
Product Weight (g) 50
Pin Count 5
Mounting Screw
Package Height 20
Package Length 75
Package Width 40
PCB changed 5
