(5 PCS) PQ30RV11J00H SHARP LDO Regulator Pos 1.5V to 30V 1A 4-Pin(4+Tab) TO-220
Tax included.
THIS LISTING IS FOR (5 PCS) OF PQ30RV11J00H BY SHARP
LDO Regulator Pos 1.5V to 30V 1A 4-Pin(4+Tab) TO-220
Manufacturer: Sharp Microelectronics
Product Category: LDO Voltage Regulators
Mounting Style: Through Hole
Package / Case: TO-220-4
Output Voltage: 1.5 V to 30 V
Output Current: 1 A
Number of Outputs: 1 Output
Polarity: Positive
Quiescent Current: 7 mA
Input Voltage MAX: 35 V
Input Voltage MIN: 4.5 V
Output Type: Adjustable
Minimum Operating Temperature: - 20 C
Maximum Operating Temperature: + 80 C
Height: 7.5 mm (Max)
Length: 10.2 mm (Max)
Width: 4.5 mm
Brand: Sharp Microelectronics
Dropout Voltage - Max: 500 mV at 500 mA
Voltage Regulation Accuracy: 2 %
Line Regulation: 2.5 %
Load Regulation: 1 %
Pd - Power Dissipation: 15 W
Product Type: LDO Voltage Regulators
Reference Voltage: 1.275 V
Factory Pack Quantity: 1000
Subcategory: PMIC - Power Management ICs
Unit Weight: 0.102093 oz
