(5 PCS) OPA379AIDCKT TI, Op Amps 1.8V 2.9uA 90kHz Rail-to-RailSC70-5 ROHS
Tax included.
THIS IS FOR (5 PCS) OFOPA379AIDCKT BY TI
Op Amps 1.8V 2.9uA 90kHz Rail-to-RailSC70-5 ROHS
Manufacturer: Texas Instruments
Product Category: Operational Amplifiers - Op Amps
RoHS: Y
Mounting Style: SMD/SMT
Package / Case: SC-70-5
Number of Channels: 1 Channel
Supply Voltage - Max: 5.5 V
GBP - Gain Bandwidth Product: 90 kHz
Output Current per Channel: 5 mA
SR - Slew Rate: 30 mV/us
Vos - Input Offset Voltage: 1.5 mV
Supply Voltage - Min: 1.8 V
Minimum Operating Temperature: - 40 C
Maximum Operating Temperature: + 125 C
Ib - Input Bias Current: 50 pA
Operating Supply Current: 2.9 uA
Shutdown: No Shutdown
CMRR - Common Mode Rejection Ratio: 100 dB
en - Input Voltage Noise Density: 80 nV/sqrt Hz
Series: OPA379
Packaging: Reel
Packaging: Cut Tape
Amplifier Type: Rail to Rail Operational Amplifiers
Brand: Texas Instruments
Features: EMI Hardened
Height: 0.9 mm
In - Input Noise Current Density: 0.001 pA/sqrt Hz
Input Type: Rail-to-Rail
Length: 2 mm
Moisture Sensitive: Yes
Operating Supply Voltage: 1.8 V to 5.5 V
Output Type: Rail-to-Rail
Product: Operational Amplifiers
Product Type: Op Amps - Operational Amplifiers
PSRR - Power Supply Rejection Ratio: 113.98 dB
250
Subcategory: Amplifier ICs
Supply Type: Single
Vcm - Common Mode Voltage: Negative Rail - 0.1 V to Positive Rail + 0.1 V
Voltage Gain dB: 120 dB
Width: 1.25 mm
Unit Weight: 0.000705 oz
