(5 PCS) N74F524 PHILIPS Bus Driver 1-Func 8-Bit Inverted Output TTL PDIP-20
Tax included.
THIS IS FOR (5 PCS) OF N74F524, 74F524D BY PHILIPS
Bus Driver 1-Func 8-Bit Inverted Output TTL PDIP-20
Part #: N74F540
Part Category: Logic ICs
Manufacturer: NXP
Description: Bus Driver, F/FAST Series, 1-Func, 8-Bit, Inverted Output, TTL, PDIP20
Mfr Package Description 0.300 INCH, EIAJ, SC603, PLASTIC, SOT-146-1, DIP-20
Status Active-Unconfirmed
Logic IC Type BUS DRIVER
Family F/FAST
JESD-30 Code R-PDIP-T20
JESD-609 Code e3/e4
Number of Bits 8
Number of Functions 1
Number of Ports 2
Number of Terminals 20
Operating Temperature-Min 0.0 Cel
Operating Temperature-Max 70.0 Cel
Output Characteristics 3-STATE
Output Polarity INVERTED
Package Body Material PLASTIC/EPOXY
Package Code DIP
Package Shape RECTANGULAR
Package Style IN-LINE
Propagation Delay (tpd) 7.5 ns
Qualification Status Not Qualified
Seated Height-Max 4.2 mm
Supply Voltage-Nom (Vsup) 5
Supply Voltage-Min (Vsup) 4.5 V
Supply Voltage-Max (Vsup) 5.5 V
Surface Mount NO
Technology TTL
Temperature Grade COMMERCIAL
Terminal Finish TIN/NICKEL PALLADIUM GOLD
Terminal Form THROUGH-HOLE
Terminal Pitch 2.54 mm
Terminal Position DUAL
Length 26.73 mm
Width 7.62 mm
Additional Feature WITH DUAL OUTPUT ENABLE
