(5 PCS) M74HC652M1 STMicro, Registered Bus Transceiver,1-Func, 8-Bit, SOIC24
Tax included.
THIS LISTING IS FOR (5 PCS) OF M74HC652M1 BY STMicro
Registered Bus Transceiver,1-Func, 8-Bit, SOIC24
Part #: M74HC652M1
Part Category: Logic ICs
Manufacturer: STMicroelectronics, Inc.
Description: Registered Bus Transceiver, HC/UH Series, 1-Func, 8-Bit, True Output, CMOS, PDSO24
Mfr Package Description MICRO, PLASTIC, DIP-24
Status Discontinued
Logic IC Type REGISTERED BUS TRANSCEIVER
Sub Category Bus Driver/Transceivers
Control Type INDEPENDENT CONTROL
Count Direction BIDIRECTIONAL
Family HC/UH
JESD-30 Code R-PDSO-G24
JESD-609 Code e0
Load Capacitance (CL) 50.0 pF
Max I(ol) 0.006 Amp
Number of Bits 8
Number of Functions 1
Number of Ports 2
Number of Terminals 24
Operating Temperature-Min -40.0 Cel
Operating Temperature-Max 85.0 Cel
Output Characteristics 3-STATE
Output Polarity TRUE
Package Body Material PLASTIC/EPOXY
Package Code SOP
Package Equivalence Code SOP24,.4
Package Shape RECTANGULAR
Package Style SMALL OUTLINE
Peak Reflow Temperature (Cel) NOT SPECIFIED
Prop. Delay@Nom-Sup 60.0 ns
Propagation Delay (tpd) 60.0 ns
Qualification Status Not Qualified
Seated Height-Max 2.65 mm
Supply Voltage-Nom (Vsup) 5
Supply Voltage-Min (Vsup) 2.0 V
Supply Voltage-Max (Vsup) 6.0 V
Surface Mount YES
Technology CMOS
Temperature Grade INDUSTRIAL
Terminal Finish Tin/Lead (Sn/Pb)
Terminal Form GULL WING
Terminal Pitch 1.27 mm
Terminal Position DUAL
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Translation N/A
Trigger Type POSITIVE EDGE
Length 15.4 mm
Width 7.5 mm
Additional Feature SELECT INPUT FOR MULTIPLEXED TRANSMISSION OF REGISTERED/REAL TIME DATA
