(5 PCS) LF33CDT, ST Micro, LDO Regulator, 3.3V, 0.5A, DPAK ROHS
Tax included.
THIS LISTING IS FOR (5 PCS) OF LF33CDT, BY ST Micro
LDO Regulator, 3.3V, 0.5A, DPAK ROHS
Regulator Topology Positive Fixed
Voltage - Output 3.3V
Current - Output 500mA
Voltage - Dropout (Typical) 0.4V @ 500mA
Number of Regulators 1
Voltage - Input Up to 16V
Current - Limit (Min) -
Operating Temperature -40°C ~ 125°C
Mounting Type Surface Mount
Package / Case TO-252-3, DPak (2 Leads + Tab), SC-63
Supplier Device Package D-Pak
