(5 PCS) FDS9431A FSC Trans MOSFET P-CH 20V 3.5A 8-Pin SOIC

$4.95
Unit price per

Tax included.

THIS LISTING IS FOR (5 PCS) OF FDS9431A BY FSC

Trans MOSFET P-CH 20V 3.5A 8-Pin SOIC

Manufacturer Fairchild Semiconductor

Series -

Packaging Cut Tape (CT)

Part Status Obsolete

FET Type P-Channel

Technology MOSFET (Metal Oxide)

Drain to Source Voltage (Vdss) 20V

Current - Continuous Drain (Id) @ 25°C 3.5A (Ta)

Drive Voltage (Max Rds On, Min Rds On) 2.5V, 4.5V

Rds On (Max) @ Id, Vgs 130mOhm @ 3.5A, 4.5V

Vgs(th) (Max) @ Id 1V @ 250µA

Gate Charge (Qg) (Max) @ Vgs 8.5nC @ 4.5V

Vgs (Max) ±8V

Input Capacitance (Ciss) (Max) @ Vds 405pF @ 10V

FET Feature -

Power Dissipation (Max) 2.5W (Ta)

Operating Temperature -55°C ~ 150°C (TJ)

Mounting Type Surface Mount

Supplier Device Package 8-SOIC

Package / Case 8-SOIC (0.154", 3.90mm Width)

Base Part Number FDS94
