(5 PCS) DS3680N TI/NSC 4 CHANNEL, BUF OR INV BASED PRPHL DRVR, PDIP14
Tax included.
THIS LISTING IS FOR (5 PCS) OF DS3680N BY TI/NSC
4 CHANNEL, BUF OR INV BASED PRPHL DRVR, PDIP14
Part #: DS3680N
Part Category: Interface ICs
Manufacturer: Texas Instruments High-Performance Analog
Description: Buffer/Inverter Based Peripheral Driver, 4 Driver, 0.1A, BIPolar, PDIP14
| Mfr Package Description |
|
| REACH Compliant | Yes |
| Status | Active |
| Interface IC Type | BUFFER OR INVERTER BASED PERIPHERAL DRIVER |
| Built-in Protections | TRANSIENT |
| Driver Number of Bits | 4.0 |
| Input Characteristics | DIFFERENTIAL |
| JESD-30 Code | R-PDIP-T14 |
| JESD-609 Code | e4 |
| Moisture Sensitivity Level | NOT APPLICABLE |
| Negative Supply Voltage-Nom | -52.0 V |
| Number of Functions | 4 |
| Number of Terminals | 14 |
| Operating Temperature-Min | 0.0 Cel |
| Operating Temperature-Max | 70.0 Cel |
| Output Characteristics | OPEN-EMITTER |
| Output Current Flow Direction | SOURCE |
| Output Polarity | TRUE |
| Package Body Material | PLASTIC/EPOXY |
| Package Code | DIP |
| Package Equivalence Code | DIP14,.3 |
| Package Shape | RECTANGULAR |
| Package Style | IN-LINE |
| Peak Reflow Temperature (Cel) | NOT SPECIFIED |
| Power Supplies (V) | -52 |
| Qualification Status | Not Qualified |
| Seated Height-Max | 5.08 mm |
| Sub Category | Peripheral Drivers |
| Surface Mount | NO |
| Technology | BIPOLAR |
| Temperature Grade | COMMERCIAL |
| Terminal Form | THROUGH-HOLE |
| Terminal Pitch | 2.54 mm |
| Terminal Position | DUAL |
| Time@Peak Reflow Temperature-Max (s) | NOT SPECIFIED |
| Turn-off Time | 10.0 µs |
| Turn-on Time | 10.0 µs |
| Length | 19.305 mm |
| Width | 7.62 mm |
