(5 PCS) DM74LS126AM FSC Bus Driver 4-Func 1-Bit True Output TTL SOIC14
Tax included.
THIS IS FOR (5 PCS) OF DM74LS126AM BY FSC
Bus Driver 4-Func 1-Bit True Output TTL SOIC14
Part #: DM74LS126AMX
Part Category: Logic ICs
Manufacturer: Fairchild Semiconductor
Description: Bus Driver, LS Series, 4-Func, 1-Bit, True Output, TTL, PDSO14
Mfr Package Description 0.150 INCH, MS-012, SOIC-14
Status Discontinued
Logic IC Type BUS DRIVER
Sub Category Bus Driver/Transceivers
Control Type ENABLE HIGH
Family LS
JESD-30 Code R-PDSO-G14
JESD-609 Code e0
Max I(ol) 0.024 Amp
Number of Bits 1
Number of Functions 4
Number of Ports 2
Number of Terminals 14
Operating Temperature-Min 0.0 Cel
Operating Temperature-Max 70.0 Cel
Output Characteristics 3-STATE
Output Polarity TRUE
Package Body Material PLASTIC/EPOXY
Package Code SOP
Package Equivalence Code SOP14,.25
Package Shape RECTANGULAR
Package Style SMALL OUTLINE
Packing Method TR
Power Supply Current-Max (ICC) 22.0 mA
Prop. Delay@Nom-Sup 18.0 ns
Propagation Delay (tpd) 22.0 ns
Qualification Status Not Qualified
Seated Height-Max 1.75 mm
Supply Voltage-Nom (Vsup) 5
Supply Voltage-Min (Vsup) 4.75 V
Supply Voltage-Max (Vsup) 5.25 V
Surface Mount YES
Technology TTL
Temperature Grade COMMERCIAL
Terminal Finish TIN LEAD
Terminal Form GULL WING
Terminal Pitch 1.27 mm
Terminal Position DUAL
Length 8.65 mm
Width 3.9 mm
