(5 PCS) CD74HCT534E HARRIS IC FF D-TYPE SNGL 8BIT 20DIP
Tax included.
THIS LISTING IS FOR (5 PCS) OF CD74HCT534E BY HARRIS
IC FF D-TYPE SNGL 8BIT 20DIP
Manufacturer: HARRIS SEMICONDUCTOR
Product Category: Flip Flops
RoHS: NO
Number of Circuits: 8
Logic Family: HCT
Logic Type: D-Type Flip-Flop
Polarity: Inverting
Input Type: TTL
Output Type: 3-State
Propagation Delay Time: 35 ns
High Level Output Current: - 6 mA
Low Level Output Current: 6 mA
Supply Voltage - Min: 4.5 V
Supply Voltage - Max: 5.5 V
Minimum Operating Temperature: - 55 C
Maximum Operating Temperature: + 125 C
Mounting Style: Through Hole
Package / Case: PDIP-20
Packaging: Tube
Function: D-Type Bus Interface
Height: 4.57 mm
Length: 24.33 mm
Operating Temperature Range: - 55 C to + 125 C
Quiescent Current: 8 uA
Series: CD74HCT534
Width: 6.35 mm
Number of Channels: 8
Number of Input Lines: 8
Number of Output Lines: 3
Operating Supply Voltage: 5 V
Product Type: Flip Flops
Factory Pack Quantity: 20
Subcategory: Logic ICs
Unit Weight: 0.042297 oz
