(5 PCS) BD744A-S BOURNS Bipolar Transistors - BJT 60V 15A PNP TO-220 ROHS
(5 PCS) BD744A-S BOURNS Bipolar Transistors - BJT 60V 15A PNP TO-220 ROHS
(5 PCS) BD744A-S BOURNS Bipolar Transistors - BJT 60V 15A PNP TO-220 ROHS

(5 PCS) BD744A-S BOURNS Bipolar Transistors - BJT 60V 15A PNP TO-220 ROHS

Tax included.
Only 100 left!
THIS IS FOR (5 PCS) OF BD744A-S BY BOURNS
Bipolar Transistors - BJT 60V 15A PNP TO-220

Part #: BD744A-S
Obsolete
Part Category:Power Bipolar Transistors
Manufacturer:BOURNS INC
Description:
Power Bipolar Transistor, 15A I(C), 60V V(BR)CEO, 1-Element, PNP, Silicon, TO-220AB, Plastic/Epoxy, 3 Pin

Status Discontinued
Case Connection COLLECTOR
Collector Current-Max (IC) (A) 15.0000000000000000
Collector-emitter Voltage-Max (V) 60.0000000000000000
Configuration SINGLE
DC Current Gain-Min (hFE) 5.0000000000000000
JEDEC-95 Code TO-220AB
JESD-30 Code R-PSFM-T3
J-STD-609 Code e1
Number of Elements 1
Number of Terminals 3
Operating Temperature-Max (Cel) 150
Package Body Material PLASTIC/EPOXY
Package Shape RECTANGULAR
Package Style FLANGE MOUNT
Polarity/Channel Type PNP
Power Dissipation-Max (W) 90.000000000000000
DLA Qualification Not Qualified
Surface Mount NO
Terminal Finish TIN SILVER COPPER
Terminal Form THROUGH-HOLE
Terminal Position SINGLE
Application SWITCHING
Transistor Element Material SILICON
