THIS LISTING IS FOR (5 PCS) OF 74408943068 BY WURTH
FIXED IND 6.8UH 2A 59 MOHM 20% SMD ROHS

Manufacturer Würth Elektronik
Series WE-SPC
Packaging Cut Tape (CT)
Part Status Active
Type Wirewound
Material - Core Ferrite
Inductance 6.8µH
Tolerance ±20%
Current Rating (Amps) 2A
Current - Saturation (Isat) 2.7A
Shielding Shielded
DC Resistance (DCR) 59mOhm Max
Q @ Freq -
Frequency - Self Resonant 34MHz
Ratings -
Operating Temperature -40°C ~ 125°C
Inductance Frequency - Test 100kHz
Mounting Type Surface Mount
Package / Case Nonstandard
Supplier Device Package -
Size / Dimension 0.189" L x 0.189" W (4.80mm x 4.80mm)
Height - Seated (Max) 0.161" (4.10mm)
