(5 PCS) 103308-5 AMP/TYCO Connector Header Thru-Hole 20 position 0.100" (2.54mm)
(5 PCS) 103308-5 AMP/TYCO Connector Header Thru-Hole 20 position 0.100" (2.54mm)
(5 PCS) 103308-5 AMP/TYCO Connector Header Thru-Hole 20 position 0.100" (2.54mm)
(5 PCS) 103308-5 AMP/TYCO Connector Header Thru-Hole 20 position 0.100" (2.54mm)
(5 PCS) 103308-5 AMP/TYCO Connector Header Thru-Hole 20 position 0.100" (2.54mm)
(5 PCS) 103308-5 AMP/TYCO Connector Header Thru-Hole 20 position 0.100" (2.54mm)

(5 PCS) 103308-5 AMP/TYCO Connector Header Thru-Hole 20 position 0.100" (2.54mm)

Tax included.
Only 100 left!
THIS IS FOR (5 PCS) OF 103308-5 BY AMP/TYCO
Connector Header Thru-Hole 20 position 0.100" (2.54mm)

Manufacturer: TE Connectivity
Product Category: Headers & Wire Housings
RoHS: No
REACH - SVHC:
Product: Headers
Type: Shrouded
Number of Positions: 20 Position
Pitch: 2.54 mm (0.1 in)
Number of Rows: 2 Row
Row Spacing: 2.54 mm (0.1 in)
Mounting Style: Through Hole
Termination Style: Solder Pin
Mounting Angle: Straight
Contact Gender: Pin (Male)
Contact Plating: Gold
Termination Post Length: 3.05 mm (0.12 in)
Series: AMP-LATCH
Tradename: AMP-LATCH
Application: Board-to-Board
Minimum Operating Temperature: - 65 C
Maximum Operating Temperature: + 105 C
Packaging: Tube
Brand: TE Connectivity
Compliance: UL; CSA
Contact Material: Copper Alloy
Current Rating: 1 A
Flammability Rating: UL 94 V-0
Housing Color: Black
Housing Material: Thermoplastic (TP)
Insulation Resistance: 5 GOhms
Product Type: Headers & Wire Housings
75
Subcategory: Headers & Wire Housings
Unit Weight: 0.142119 oz
