(4 PCS) 2N2405 SILICON SYSTEMS Trans GP BJT NPN 90V 3-Pin TO-39
(4 PCS) 2N2405 SILICON SYSTEMS Trans GP BJT NPN 90V 3-Pin TO-39

(4 PCS) 2N2405 SILICON SYSTEMS Trans GP BJT NPN 90V 3-Pin TO-39

Tax included.
Only 55 left!
THIS LISTING IS FOR (4 PCS) OF 2N2405 BY SILICON SYSTEMS
Trans GP BJT NPN 90V 3-Pin TO-39

Product Category: Bipolar Transistors - BJT
Mounting Style: Through Hole
Package / Case: TO-39
Transistor Polarity: NPN
Configuration: Single
Collector- Emitter Voltage VCEO Max: 90 V
Collector- Base Voltage VCBO: 120 V
Emitter- Base Voltage VEBO: 7 V
Collector-Emitter Saturation Voltage: 500 mV
Maximum DC Collector Current: 150 mA
Gain Bandwidth Product fT: 50 MHz
DC Collector/Base Gain hfe Min: 60
DC Current Gain hFE Max: 200
